Aquaculture Fishing Farming Cage Factory
aquaculture fish farming cages fish farming cage UV Protected China Aquaculture Tilapia fish farming cages
Structure:
* Framework : Polyethelene Tube with reliable strength, elasticity, ductility.
* Fixed System : Timber Pile, Anchor Pile, Cement Concrete Pile, according to the geology condition of the cage location.
* Netting :use PE/ Polyester/ Nylon Knotless Nets, which have strong adhesion resistance and ageing resistance.
Common Specification:
| Cage Type | Floating Pipe Size (mm) | Rail Pipe Size (mm) | Cage Body Spec. (m) |
| Square Cage | Φ200, Φ250 | Φ110 | 5x5, 6x6, 9x9, 10x10 |
Floating Cage (Double Floating Pipes) | Φ250, Φ280, Φ315 | Φ110 | Circumference 40, 60, 80, 100 |
Floating Cage (Three Floating Pipes) | Φ250, Φ280, Φ315 | Φ110 | Circumference 60, 80, 100 |
Performance Parameter :
| Cage Type | Wind Resistance | Billow Resistance | Current Resistance | Antifouling Validity | Installation Sea Area |
| Square Cage | 8 Grade | 7 Meters | < 1M / Sec. | 6 Months | Inshore Bay |
| Floating Cage | 11 Grade | 7 Meters | < 1M / Sec. | 6 Months | Water Depth 12-20M |
| Elevating Cage | 12 Grade | 7 Meters | < 1M / Sec. | 6 Months | Water Depth 20-30M |
Net cage type | Square or circular |
Material | HDPE/ Nylon/polyester/UHMWHDPE(Dyneema) |
Knot type | Knotted /Knotless |
Weaving | Twisted/Raschel/braided |
Twine type | Multifilament |
Thickness/twine size | 190D-500D/5ply-1200ply, φ0.3mm-φ12mm |
Mesh size | 10mm-1000mm |
Mesh type | Diamoned or square |
Length×Width×Depth for square net cage Diameter×Depth for circular net cage | As request |
Color | As request |
Treatment | UV,resin,Coating, Painting |
Packing | PE woven bag |
Application | Trout,Salmon,ALMON,Sturgeon,tilapia,Catfish,Grouper,Cod,Sea bream,Etc. |
